VICTRIP® R5 Foldable Electric Bike
- COLOR:
- White
- Free:
- Reflective Vest
Pairs well with
PERFORMANCE
Battery: 960Wh (48V 20Ah) LG cells
Motor: 250W Brushless Gear Motor
Top Speed: 25 KM/H
Range (Throttle): 65 KM
Range (PAS): Up to 100 KM
Charge Time: 4-5 Hours
Charger: 48V 5A Lithium Battery Charger
Controller: 48V, 20A Current Limit
Suspension: Front Adjustable
Torque: 80Nm
Throttle: Half-Twist Throttle
Gearing & Rear Derailleur: 7-Speed
Maximum Climbing Degree: 30° - 35°
Waterproof Rating: IP65 (Including Motor, Battery, Display, and Wiring)
Riding Modes: Pure Electric, Power-Assisted, Pedal, Walking Mode
FRAMESET
Frame: High Carbon Steel
Inner Tubes: 20" x 4.0"
Chain: 114 Segments
Crank Set: 48T × 170mm
Pedals: 9/16", Aluminum
Brakes: 180mm Front & Rear Hydraulic Brakes
E-Bike Weight: 78 lbs (Battery Not Included)
Battery Weight: 12 lbs
Package Weight: 102 lbs
Packing Size: 148 × 31 × 73 cm
Rider Weight Limit: 400 lbs
Recommended Rider Height: 5'3" - 6'5"
Seat Height: 33"
Size Guide
A - Total Length: 69.3 in
B - Handlebar to Ground Height: 49.6 in
C - Seat to Ground Height: 28.3 in
D - Seat Length: 15 in
E - Handlebar Length: 24.4 in
F - Wheelbase: 51.2 in
G - Stand Height: 26.4 in
H - Wheel Diameter: 23.2 in
What's in the Box ?
R5 E-bike *1
48V20Ah Battery*1
Display*1
Battery Charger*1
Assembly Tools*1
Pedals *2
Key*4
User Manual *1
Rear seat + backrest *1 set
Rear passenger footrest *1 pair
Front fender*1+Rear fender*1
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, within 24 hours on weekdays.
Shipping Information
Use this text to answer questions in as much detail as possible for your customers.
Customer Support
Use this text to answer questions in as much detail as possible for your customers.
FAQ’s
Use this text to answer questions in as much detail as possible for your customers.
Contact Us
Use this text to answer questions in as much detail as possible for your customers.
48V20Ah
LG Lithium-Ion Battery
65-100 KM
Range
250W
Motor
25KM/H
Speed
WHAT IS R5?
From city streets to rugged trails, the R5 is built to conquer any terrain. Powered by an LG 48V 20Ah tubular lithium battery, it delivers an impressive range of up to 100KM. With 80Nm of torque, it effortlessly tackles inclines of 30-35 degrees. Its mid-step frame, wide tires, and full suspension system provide exceptional comfort and stability. Whether you're commuting or exploring, the R5 combines power, style, and adventure for an exhilarating ride every time.
Dual shock system
Inspired by suspension design, front and rear shock absorbers provide superior comfort and stability. The system features two shock absorbers that effectively handle bumps and provide a smoother ride. Whether on asphalt, dirt or rocky surfaces, this design ensures optimal performance and a more controlled ride.
20'' x 4.0''Fat Tire
Both the front and rear feature 20'' x 4.0'' integrated 10-piece straight-rib tires, designed for maximum stability and durability. Built for strength and performance, these tires excel on flat roads, mountain trails, snow, and gravel, delivering superior grip and control on any terrain.
Discover the Power of R5 E-Bikes ➕get more
Motor ➠
The R5 features a powerful 250W rear-drive motor, reaching speeds over 25KM and delivering up to 80Nm of torque. With peak speeds exceeding 10,000rpm, it offers unmatched performance. The durable one-piece, 10-blade straight-rib rear wheel ensures stability, making it ideal for tough terrains. Designed for low noise, smooth operation, and high efficiency, the motor excels in both power and reliability. Paired with an advanced 5-level Pedal Assist System (PAS), it ensures seamless power delivery, excellent heat resistance, and long-lasting durability – perfect for conquering all terrains and long-distance rides.
Battery
The Victrip R5 is powered by a high-capacity LG 48V20Ah battery with UL-certified 21700 cells, offering 6% higher energy density, enhanced power output, and an impressive 90+KM range in pedal-assist mode.
The battery features an advanced management system (BMS) to prevent overcharging, over-discharging, and short-circuiting, ensuring safety and reliability. Its quick-release design makes replacement and maintenance effortless, while the IP65 waterproof rating guarantees dependable performance in various environments.
With a fast 3-4 hour charge time and rigorous safety testing, the R5 delivers exceptional range, durability, and peace of mind for any ride.
Brake
The sensitive braking system, with 180mm large-disc hydraulic brake discs at the front and rear, can provide sufficient braking force in a short distance on both wet and dry roads.
suspension
Adjustable suspension
The right rotary adjustment button can adjust the hardness of the suspension, with a maximum adjustment range of 60mm, helping you cope with different road conditions and ensuring a smooth and safe ride.
Throttle
The R5's half-twist throttle ensures precise speed control with minimal effort, reducing unintended acceleration on rough roads or when starting off. It is compatible with riding accessories to increase safety, convenience and stability, making it perfect for daily commuting and rough terrain.
Lighting
The Victrip R5 electric bike is equipped with a comprehensive high-performance lighting system, ensuring greater safety and convenience when riding at night or on complex road conditions. The integrated taillight and brake light enhance visibility and provide a clear signal to vehicles and pedestrians when slowing down. The rear left and right turn signals make your turning intentions clear, improving road safety. Additionally, the powerful LED headlight offers excellent illumination on dimly lit streets or remote paths, ensuring clear visibility. These thoughtful features enhance your riding experience, making every journey safer and more efficient.
DISPLAY
The IP65 LCD display provides riders with essential information, including current speed, battery level, and mileage. This real-time feedback enables riders to monitor their ride more effectively and make informed decisions.
It also comes with a USB port for easy charging while on the go.
Seat
One-piece shelve is more stable and durable.
The leather cushion and backrest are removable, so you can change them according to your needs.(Can be fitted with rear basket, rearseat bag or child safety seat)
The folding rear passenger footrest is convenient for passengers to get on and off the vehicle.
size
With just 3 simple steps, R5 can be folded up in 15 seconds.
It can be folded and carried in various scenarios, including subways, elevators, buses and car trunks. Very easy to store or take with you on a trip.
Folded size:37*25*31(inches)
pedals
The R5 introduces an innovative design for its footrests, enhancing user convenience. The foldable footrests not only make it easier to store and place the bike but also improve stability, reducing the likelihood of bumps during rides.
Product details
In the Box
R5 E-bike *1
48V20Ah Battery*1
Display*1
Battery Charger*1
Assembly Tools*1
Pedals *2
Key*4
User Manual *1
Rear seat + backrest *1 set
Rear passenger footrest *1 pair
Front fender*1+Rear fender*1
Specification
Battery: 48V 20Ah
Range: Up to 100KM
Motor: 250W
Tires: 20" x 4" puncture-resistant
Lights: Headlights, taillights, and brake lights
Charger: Lithium battery charger 48V 5A
Controller: 48V 18A current limit
Display: Smart LCD display
Bike Weight: 78lbs (excluding battery)
Payload Capacity: 400lbs
Recommended Rider Heights: 5'3" to 6'5"
Pedal Assist: 0-5 Level Pedal Assist
Throttle: Half-Twist throttle
Front Handlebar: Lock and adjustment function
E-system & Drivetrain
E-system & Drivetrain
Battery
48V20Ah (960Wh)
Fast Charger
48V 5A
Display Type
Smart LCD Display
Rear Derailleur
Shimano 7 speed
Weight & Dimensions
Weight
34kg / 78 lbs
Weight limit
Maximum total weight limit (combined weight of rider and cargo) of 400 pounds (180kg).
Folded Dimensions
37*25*31 inch
Unfolded Dimensions
69.3*22*50 inch
Included in the Box
R5
Toolkit
charger
Four keys
Manual
Fender
SMART LIGHT
The Victrip R5 features a high-performance lighting system for enhanced safety and convenience. Its integrated taillight, brake light, and turn signals improve visibility and road safety. A powerful LED headlight ensures clear illumination in low-light conditions, making every ride safer and more efficient.
LEARN MORE
More detailed feature introduction for the Victrip-R5 Electric Bicycle.
Adjustable Front Fork
Open for shock absorption, close for no shock absorption, easily adjustable to enhance ride comfort.
Adjustable Seat
Customizable to your height for a comfortable riding experience.
7-Speed Adjustment
Select the ideal gear based on terrain for smooth riding in any.
R5 Size
A - Total Length: 69.3 in
B - Handlebar to Ground Height: 49.6 in
C - Seat to Ground Height: 28.3 in
D - Seat Length: 15 in
E - Handlebar Length: 24.4 in
F - Wheelbase: 51.2 in
G - Stand Height: 26.4 in
H - Wheel Diameter: 23.2 in
Folded size
With just 3 simple steps, R5 can be folded up in 15 seconds.
It can be folded and carried in various scenarios, including subways, elevators, buses and car trunks. Very easy to store or take with you on a trip.
Folded size:37*25*31(inches)
FAQs-R5
What is the weight of the bike ?
Total weight of R5 folding ebike is 102 lbs: the bike weight is 78 lbs, the battery weight is 12 lbs.
What is the difference between R5 and R5S?
The R5S features a low-step design, making it ideal for seniors and women in skirts, offering easier mounting and dismounting. The R5 has a medium-step design, tailored for men and cross-country riders. Aside from the step design differences, both models share the same functions and features.
How to start the power supply?
1.To unlock the R5, insert the key into the keyhole located at the bottom of the frame and on the right side of the handlebar simultaneously, then rotate it clockwise by one full turn.
2.To unlock the R5S, simply insert the key into the keyhole on the right side of the handlebar and rotate it clockwise by one full turn.
What are the features of the R5 tire?
The R5 features one-piece wheels, which are stronger, more durable, and offer superior load capacity compared to traditional spoked wheels.
If you prioritize low maintenance, high durability, and excellent shock absorption, one-piece wheels are the perfect choice for city commuting, long-distance riding, and rough terrains. They provide a hassle-free experience with outstanding riding comfort.
What is the difference between the R5 and JANUS 2.0 series?
The R5 series is a comprehensive upgrade to the JANUS 2.0, offering an enhanced and superior riding experience. Key improvements include a front and rear suspension system for exceptional comfort and stability, along with three stylish color options: black, white, and orange. The 20-inch one-piece 10-blade aluminum alloy wheels provide durability and better handling. Additional upgrades include a rear seat cushion, passenger backrest, and foldable passenger footrests for added convenience. The R5 is also equipped with an upgraded high-beam front light, premium leather half-turn throttle, and a large LED display, ensuring unmatched safety, control, and style for riders.
Why are there 4 keys?
R5: The 4 keys include:
2 keys to open the throttle
2 keys to lock the battery and turn on the power.
Can I transport R5 in a car trunk?
R5 can be folded and stored in a car trunk. Its folded dimensions are 37*25*31 inch, and its unfolded dimensions are 69.3*22*50 inch.
Can I Ride R5 in The Rain?
Though Victrip e-bikes are designed to handle wet conditions, please keep in mind that riding in heavy rain may affect battery life and reduce traction, so exercise caution and avoid riding in the rain as much as possible. As for the waterproof level, the whole bike meets IPX4 standards; the motor, battery, and display meet IP64 standards.
What Types of Terrain Can R5 Handle?
R5 ebikes are designed for off-road use on rugged, unpaved surfaces with their wide and fat tires. These surfaces include dirt trails, gravel roads, grass, sand, and light snow. They can handle rougher terrains better than bikes with narrow road tires, but may still struggle on very technical mountain trails. R5 is also suitable for all-season use.
Are R5 E-Bikes Suitable for All Ages and Fitness Levels?
Victrip e-bikes are generally suitable for a wide range of ages (above 16 years old) and fitness levels, as the electric motor provides adjustable assistance to accommodate different riding abilities. Besides, please note the max load for R5 is 400 lbs, and please consult with a healthcare professional if you have any health concerns before riding.
Does my height/weight suit the R5?
The recommended rider height for R5 is 5'3" ~ 6'5"; The total payload capacity of R5 is 400 lbs (not including the bike weight).
Is my R5 pre-assembled?
The R5 is partially assembled. You have to install some parts by yourself, such as the front wheel, handlebar, saddle, pedals, and fender. You can download the R5 user manual or look at the assembly video for help.
Do I need to pay taxes?
Tax-Free
Buy directly from the VICTRIP EBIKE brand website and enjoy tax-free benefits. Consumers do not need to pay 5%-15% sales tax because VICTRIP EBIKE will bear the sales tax.
Compared with Amazon, you can save up to $70 in taxes for each electric bike purchased. For example, the price of buying a TITAN S model (including tax) on other platforms is $1294, but on our brand website, it is only $1199, which directly saves you $95.
What is the warranty?
1-year warranty
1️⃣ Free Repair Services: During the warranty period, if you encounter any product quality issues, you can enjoy the following free repair services:
a) Provide relevant videos and information, and we will send you replacement parts by courier.
b) Provide relevant videos and information, and you can choose to repair it at a nearby repair shop. Submit proof of payment and we will reimburse the repair costs.
2️⃣ Free Replacement: If the product cannot be repaired during the warranty period, we will provide a free replacement.
3️⃣ 24/7 Professional Support: Our dedicated technical team is available 24/7 to offer prompt after-sales support and technical assistance.
⚡ Choose us for worry-free warranty service and a smoother riding experience!
SHIPPING
3-8 Days Delivery
📦 Shipping Tips
1️⃣ Quick Order Processing: Our professional logistics team works around the clock to ensure your order is packed and shipped within 1-2 business days. Delivery typically takes 3-8 business days, depending on the courier's speed.
2️⃣ Smart Warehouse Dispatch: With 6 warehouses across the US, we automatically select the nearest warehouse to ship your order, ensuring faster delivery.
3️⃣ Multiple Carrier Options: We work with FedEx, UPS, DHL, and other carriers offering signature services to keep your package safe.
4️⃣ Tracking Updates: Logistics tracking information may take up to 3 business days to update. Thank you for your patience.
5️⃣ Seamless Delivery Experience: From order placement to delivery, we strive to get your products to you as quickly as possible for a worry-free shopping experience.
⚡ Shop with Confidence, Receive with Ease!
Customer Reviews
I recently got an R520 folding e-bike to handle my new job commute. It's not too far, but walking is too time consuming and driving seems unnecessary. This bike solved my needs perfectly. The first time I rode it, I was immediately attracted by its stability, and the combination of the 750W motor and 48V battery made it easy for me to cope with all kinds of road conditions, especially those small hills. The LCD display allows me to keep track of the speed and power level, so I feel especially confident when riding. What surprised me most is its folding function, I can easily put it in the corner of the office, and it doesn't take up any space at all. The five levels of pedal assist are also very useful, allowing me to adjust the intensity of my ride according to the state of the day. Now, my commute is not only efficient, but also full of fun!
Ive had my bike for about 3 months and ridden it daily. It has so much power even for going up steep hills the pedal assist is so good and if you dont feel like paddling, you can just use the throttle. Im a bigger girl and it doesnt have one problem. I bought the long range batterie and it goes for a really long time before I have to charge it. I take my daughter to school and pick her up we go everywhere on it. I think its made extremely well and most definitely worth the money. The only problem Ive had with it is the reflector on the wheel rattles from time to time however, it doesnt bother me bad enough to fix it. If your looking to get this bike for the price you wont regret it. Oh, one last thing you can adjust the settings to your needs meaning when I first got the bike, it was set that thepedal assist would give you 50% of the power which was way too much for me. You get on it and it was like blowing off your seat. It was so much power so I adjusted it so it was more like 25% of the power in pedal assist gear one. Its easy to do. There is a YouTube video on it and it just have to go in the settings and adjust it. There is also a really bright light for night riding. We will be buying another one its so much fun my husband fights with me over who gets to ride it.
This extraordinary bike has all the necessary attributes and exceeds expectations in many ways. As a resident of a bustling city center, this bike has completely changed my daily commute, making it an absolute game-changer. Just as advertised, I can use the throttle directly, the maximum speed reaches 28MPh, which propels me forward effortlessly, and if I choose to pedal, I will be able to use it for a week per full charge, damn the powerful battery. Moreover, as a person of taller stature, the impeccable design of this bike makes it a perfect match for my stature.The user-friendly interface of the bike, with conveniently located activation and control keys, adds to its appeal. Moreover, the presence of lights is a valuable aid during night riding, ensuring optimal visibility and safety. Moreover, the inclusion of a horn proved to be invaluable, effectively avoiding dangerous drivers and pre-warning pedestrians that I was coming.Finally, the unparalleled foldability of the bike deserves special mention. It can be quickly folded into a compact form in just ten seconds, which allows me to store it in the back of my hatchback without any trouble, without the need for a separate bike rack, which brings me unparalleled convenience. Without a doubt, this feature embodies the bikes most extraordinary attribute.All in all, this bike transcends the realm of excellence and effortlessly meets all of my requirements and more. I wholeheartedly recommend this extraordinary mode of transportation to anyone living in the city center or elsewhere, as it embodies a rare combination of exceptional functionality and exhilarating recreation.
The concept of the bike is awesome! It folds up small. Very comfortable to ride. Ours is a bit shaky inside so the front and rear shocks are the biggest help. I've worn out several bikes and only choose Victrip. The service is great. Although there was a little incident when receiving the package, the customer solved it in a flash, which is great. The simplest form factor takes you where you want to go. There is no boost level for pedal assist. Just basic pedal assist and twist throttle. Love it off-road. Great for the city. I haven't run out of the battery yet. I don't drive it anymore except when it snows because this bike replaced it. I also like that it is unique enough that not many people will want to steal it. But I still lock it up. I will definitely buy this again.
